Call for Price
High-capacity 60 GHz radio that supports long-distance PtP (bridge) and PtMP links.
Category :
SKU :
Payment Methods:
High-capacity 60 GHz radio that supports long-distance PtP (bridge) and PtMP links.
| Data transmission | |
|---|---|
| Maximum data transfer rate | 2500 Mbit/s |
| Maximum transfer distance | 15000 m |
| Antenna | |
| Antenna gain level (max) | 46 dBi |
| Antenna design | Internal |
| Antenna type | Internal |
| Wireless LAN features | |
| Frequency band | 57 – 71 GHz |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, QPSK |
| Antenna gain level (max) | 46 dBi |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Antenna type | Internal |
| Network | |
| Networking standards | IEEE 802.11ax |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 2500 Mbit/s |
| Frequency band | 57 – 71 GHz |
| Ports & interfaces | |
| Ethernet LAN | Yes |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
| Security | |
| Security algorithms | WPA2-PSK |
| Features | |
| Product type | Network bridge |
| Reset button | Yes |
| Processor family | ARM Cortex |
| Processor model | ARM Cortex-A53 |
| RAM type | DDR3L |
| Processor frequency | 1400 MHz |
| Network Time Protocol (NTP) client | Yes |
| International Protection (IP) code | IPX6 |
| Power LED | Yes |
| Material | Aluminium, Plastic |
| LED indicators | GPS, LAN, Link, Power |
| Internal memory | 512 MB |
| Product colour | White |
| Processor manufacturer | ARM |
| Mounting type | Pole |
| Power | |
| Power consumption (max) | 26 W |
| Power source type | DC, PoE |
| DC input voltage | 44 – 54 |
| Power over Ethernet (PoE) | Yes |
| DC output voltage | 48 V |
| Operational conditions | |
| Operating temperature (T-T) | -40 – 60 °C |
| Operating relative humidity (H-H) | 5 – 95% |
| Operating temperature (T-T) | -40 – 140 °F |
| Management features | |
| LED indicators | GPS, LAN, Link, Power |
| Certificates | |
| Certification | FCC, IC, CE |
| Technical details | |
| Operating temperature (T-T) | -40 – 140 °F |
| Material | Aluminium, Plastic |
| Internal memory | 512 MB |
| Product colour | White |
| Quantity per pack | 1 pc(s) |
| Weight & dimensions | |
| Weight | 2.8 kg |
| Width | 424.4 mm |
| Depth | 424.4 mm |
| Height | 166.2 mm |
| Processor | |
| Processor family | ARM Cortex |
| Processor model | ARM Cortex-A53 |
| Processor frequency | 1400 MHz |
| Processor manufacturer | ARM |
| Memory | |
| RAM type | DDR3L |
| Indication | |
| Power LED | Yes |
| Packaging content | |
| Quick installation guide | Yes |
| Mounting bracket(s) included | Yes |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
